TEN 60-2413WIR

TEN 60-2413WIR is listed in the DC DC Converters range at ChipApex. The manufacturer field lists Traco Power. Its product description is DC DC CONVERTER 15V 60W. Review the specifications below when checking this part for your BOM.

DC DC Converters specifications for TEN 60-2413WIR

• Description：DC DC CONVERTER 15V 60W
• Series：TEN 60WIR (60W)
• Mfr：Traco Power
• Package：Box
• Type：Isolated Module
• Number of Outputs：1
• Voltage - Input (Min)：9V
• Voltage - Input (Max)：36V
• Voltage - Output 1：15V
• Voltage - Output 2：-
• Voltage - Output 3：-
• Voltage - Output 4：-
• Current - Output (Max)：4A
• Power (Watts)：60 W
• Voltage - Isolation：3 kV
• Applications：ITE (Commercial), Railway
• Features：Adjustable Output, Remote On/Off
• Operating Temperature：-40°C ~ 85°C (With Derating)
• Efficiency：93%
• Mounting Type：Through Hole
• Package / Case：8-DIP Module
• Size / Dimension：2.00" L x 1.60" W x 1.00" H (50.8mm x 40.7mm x 25.4mm)
• Supplier Device Package：-
• Control Features：-
• Approval Agency：-
• Standard Number：-
• Grade：-
• Qualification：-

DC DC Converters datasheet and documents for TEN 60-2413WIR
