TG2016SBN 19.2000M-KCGNCM5

Oscillators Overview

The TG2016SBN 19.2000M-KCGNCM5 is a voltage-controlled temperature-compensated crystal oscillator (VCTCXO) manufactured by Epson Timing. It operates at a nominal frequency of 19.2 MHz and utilizes a sine wave output format. The device supports a supply voltage range of 2.5 V to 3.3 V and is housed in a compact 4-SMD, no-lead package with dimensions of 2.0 mm x 1.6 mm. It features a frequency stability of +/- 0.5 ppm over an operating temperature range of 0°C to +85°C.

Oscillators Feature Summary

• Voltage-controlled operation allows for precise frequency tuning via an external control voltage.
• Temperature compensation ensures high frequency stability across the specified industrial temperature range.
• Compact surface-mount package design facilitates integration into space-constrained electronic circuits.

Oscillators Applications

• Precision timing applications requiring stable clock signals
• Communication systems utilizing 19.2 MHz reference frequencies
• Embedded devices needing low-power, high-stability oscillators

Oscillators Procurement Notes

Verify that the specific suffix KCGNCM5 matches the required frequency tolerance and temperature range specifications for your application. Confirm the package type and pin configuration align with your PCB footprint requirements before finalizing procurement orders.

Oscillators Selection Notes

Select this component when a voltage-controlled TCXO is required for 19.2 MHz applications. Ensure the system design accommodates the necessary control voltage input for frequency adjustment and provides a stable power supply within the 2.5 V to 3.3 V operating range.

Oscillators Part Context

This part belongs to the TG2016SBN series of VCTCXOs from Epson Timing. The series is designed for applications demanding high precision and stability in small form factors. Other variants in the series may offer different frequencies or tolerance levels while maintaining similar package and operational characteristics.

Oscillators Replacement Considerations

Direct substitutes must match the 19.2 MHz frequency, VCTCXO functionality, 4-SMD package, and +/- 0.5 ppm stability. Verify compatibility with existing control voltage requirements and thermal management needs before substitution.
