THMC0421SP-100MG is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists TAI-TECH Advanced Electronics Co., Ltd.. Its product description is IND 10UH 145MOHM 2.9A. Review the specifications below when checking this part for your BOM.
Fixed Inductors specifications for THMC0421SP-100MG
- Description：IND 10UH 145MOHM 2.9A
- Series：THMC0421SP-G
- Mfr：TAI-TECH Advanced Electronics Co., Ltd.
- Package：Tape & Reel (TR),Cut Tape (CT)
- Type：Wirewound
- Material - Core：Metal
- Inductance：10 µH
- Tolerance：±20%
- Current Rating (Amps)：2.9 A
- Current - Saturation (Isat)：3A
- Shielding：Unshielded
- DC Resistance (DCR)：145mOhm Max
- Q @ Freq：-
- Frequency - Self Resonant：-
- Ratings：-
- Operating Temperature：-40°C ~ 125°C
- Inductance Frequency - Test：100 kHz
- Mounting Type：Surface Mount
- Package / Case：Nonstandard
- Supplier Device Package：-
- Size / Dimension：0.169" L x 0.161" W (4.30mm x 4.10mm)
- Height - Seated (Max)：0.083" (2.10mm)
- Features：-
Fixed Inductors datasheet and documents for THMC0421SP-100MG
Fixed Inductors Overview
The THMC0421SP-100MG is an unshielded wirewound inductor manufactured by TAI-TECH Advanced Electronics. It features a nominal inductance of 10 µH and supports a maximum current rating of 2.9 A. The component exhibits a maximum DC resistance of 145 mOhm. It utilizes a nonstandard package configuration suitable for surface-mount applications.
Fixed Inductors Feature Summary
- Unshielded wirewound construction
- Nonstandard package form factor
Fixed Inductors Applications
- Power supply filtering circuits
- Energy storage in switching regulators
- Signal processing choke applications
Fixed Inductors Procurement Notes
Verify the specific manufacturer datasheet to confirm exact dimensional tolerances and thermal characteristics. Ensure compatibility with standard reflow soldering profiles. Cross-reference the part number suffix to confirm the presence of lead-free plating and RoHS compliance status before finalizing procurement orders.
Fixed Inductors Selection Notes
Select this component when a 10 µH inductance value is required with a 2.9 A current handling capability. The 145 mOhm DC resistance indicates moderate conduction losses. Consider the unshielded design implications for electromagnetic interference coupling in dense layouts compared to shielded alternatives.
Fixed Inductors Part Context
This model belongs to the THMC0421SP series from TAI-TECH, which specializes in magnetic components. The series includes various inductance values ranging from microhenries to higher ranges, all utilizing wirewound technology. The manufacturer focuses on producing these components using proprietary magnetic materials.
Fixed Inductors Replacement Considerations
Direct substitutes include other 10 µH unshielded wirewound inductors with similar current ratings. Verify that alternative parts meet the 145 mOhm DC resistance limit and fit the nonstandard footprint constraints.
