THP-1225+

$24.31

Description：RF FILTER HIGH PASS 2.61GHZ 8SMD
Series：-
Mfr：Mini-Circuits
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:211b3839cad7 Category: RF Filters Brand: Mini-Circuits

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：RF FILTER HIGH PASS 2.61GHZ 8SMD
Series：-
Mfr：Mini-Circuits
Package：Tape & Reel (TR),Cut Tape (CT)
Frequency：2.61GHz Center
Bandwidth：2.775GHz
Filter Type：High Pass
Ripple：-
Insertion Loss：2dB
Mounting Type：Surface Mount
Package / Case：8-SMD, No Lead
Size / Dimension：0.250" L x 0.250" W (6.35mm x 6.35mm)
Height (Max)：0.100" (2.54mm)

Download product information

THP-1225+

Overview

The Mini-Circuits THP-1225+ is a surface-mount high-pass filter designed for RF applications. It operates within a frequency range of 10 MHz to 4000 MHz and maintains a 50Ω impedance rating. The component features compact dimensions of 0.25 inches by 0.25 inches by 0.10 inches. It utilizes SMT technology for integration into printed circuit boards. The device provides a center frequency of 2.61 GHz with a bandwidth of 2.775 GHz.

Feature Summary

Surface-mount construction using SMT technology
High-pass filtering capability across specified RF bands
Compact physical footprint for board space efficiency

Applications

RF signal processing systems
Wireless communication infrastructure
Test and measurement equipment

Procurement Notes

Verify the specific datasheet version against the manufacturer's official documentation to confirm electrical characteristics and mechanical drawings. Ensure compatibility with standard reflow soldering profiles for SMD components. Confirm that the 50Ω impedance matches system requirements before integration.

Selection Notes

Select this component when a high-pass filter is required for frequencies starting from 10 MHz up to 4 GHz. Consider the small form factor for dense PCB layouts. Verify that the insertion loss and rejection specifications meet the specific application needs compared to other Mini-Circuits filter series.

Part Context

This part belongs to the Mini-Circuits family of RF filters, which are widely used in telecommunications and industrial electronics. The company specializes in signal processing devices including amplifiers, mixers, and couplers. The THP-1225+ represents their surface-mount product line aimed at modern manufacturing processes.

Replacement Considerations

Consult official Mini-Circuits substitution guides for compatible alternatives. No direct public substitute part numbers are confirmed in the provided source material.
