THR 3-4813WI

THR 3-4813WI is listed in the DC DC Converters range at ChipApex. The manufacturer field lists Traco Power. Its product description is 3 WATT DC/DC CONVERTER, INDUSTRI. Review the specifications below when checking this part for your BOM.

DC DC Converters specifications for THR 3-4813WI

• Description：3 WATT DC/DC CONVERTER, INDUSTRI
• Series：THR 3WI (3W)
• Mfr：Traco Power
• Package：Tube
• Type：Isolated Module
• Number of Outputs：1
• Voltage - Input (Min)：18V
• Voltage - Input (Max)：18V
• Voltage - Output 1：15V
• Voltage - Output 2：-
• Voltage - Output 3：-
• Voltage - Output 4：-
• Current - Output (Max)：200mA
• Power (Watts)：3 W
• Voltage - Isolation：3 kV
• Applications：ITE (Commercial)
• Features：-
• Operating Temperature：-40°C ~ 92°C (With Derating)
• Efficiency：84%
• Mounting Type：Through Hole
• Package / Case：24-DIP Module, 5 Leads
• Size / Dimension：1.25" L x 0.80" W x 0.47" H (31.8mm x 20.3mm x 12.0mm)
• Supplier Device Package：-
• Control Features：-
• Approval Agency：CB, cURus
• Standard Number：62368-1
