TJC3-3AWJ UL (WT)

Headers, Male Pins Overview

The TJC3-3AWJ UL (WT) is a header connector manufactured by CWB Electronics Inc., designed for vertical or right-angle PCB mounting. It features a 2.5mm pitch and provides three positions for electrical interconnection. The component utilizes a wire-to-board configuration, facilitating reliable connections in automotive and consumer electronics applications. The housing is constructed to support quick connector systems, ensuring secure mating with corresponding terminals.

Headers, Male Pins Feature Summary

• Supports vertical and right-angle mounting configurations for flexible PCB layout integration
• Utilizes a 2.5mm pitch design for standardized spacing between contact positions
• Engineered for use in quick connector systems within automotive and consumer electronics

Headers, Male Pins Applications

• Automotive electronic component interconnections
• Consumer electronics assembly requiring quick connectors
• Wire-to-board signal transmission in compact devices

Headers, Male Pins Procurement Notes

Verify the specific orientation (vertical vs. right-angle) and terminal compatibility before procurement. Confirm that the 2.5mm pitch matches the system requirements. Ensure the UL certification and WT designation align with safety and regulatory standards for the intended application environment. Cross-reference the exact part number suffix to confirm housing type and pin count.

Headers, Male Pins Selection Notes

Select this component when a three-position header with a 2.5mm pitch is required for automotive or consumer electronics. Consider the mounting style options available within the TJC3 series. Ensure compatibility with existing quick connector terminal sets. Evaluate space constraints on the PCB to determine if vertical or right-angle mounting best suits the mechanical design.

Headers, Male Pins Part Context

This part belongs to the TJC3 series of rectangular connectors from CWB Electronics Inc., which specializes in automotive and consumer electronic components. The series includes various position counts and mounting styles, all sharing the 2.5mm pitch characteristic. The TJC3-3AWJ variant specifically denotes a three-position header, fitting into the broader family of quick connector solutions offered by the manufacturer.

Headers, Male Pins Replacement Considerations

Compatible substitutes include other TJC3 series headers with matching 2.5mm pitch and three positions, such as TJC3-3A or TJC3-3Y variants, provided the mounting orientation and housing material specifications are identical. Verify terminal compatibility before substitution.
