TJC3-8AWJ UL (WT)

$0.22

Description：CONN HEADER R/A 2POS 2.5MM
Series：*
Mfr：CWB Electronics Inc.
Package：Bulk

SKU:d2ee6d4c2357 Category: Headers, Male Pins Brand: CWB Electronics Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

TJC3-8AWJ UL (WT) is listed in the Headers, Male Pins range at ChipApex. The manufacturer field lists CWB Electronics Inc.. Its product description is CONN HEADER R/A 2POS 2.5MM. Review the specifications below when checking this part for your BOM.

Headers, Male Pins specifications for TJC3-8AWJ UL (WT)

Description：CONN HEADER R/A 2POS 2.5MM
Series：*
Mfr：CWB Electronics Inc.
Package：Bulk
Connector Type：-
Contact Type：-
Pitch - Mating：-
Number of Positions：-
Number of Rows：-
Row Spacing - Mating：-
Number of Positions Loaded：-
Style：-
Shrouding：-
Mounting Type：-
Termination：-
Fastening Type：-
Contact Length - Mating：-
Contact Length - Post：-
Overall Contact Length：-
Insulation Height：-
Contact Shape：-
Contact Finish - Mating：-
Contact Finish Thickness - Mating：-
Contact Finish - Post：-
Contact Material：-
Insulation Material：-
Features：-
Operating Temperature：-
Ingress Protection：-
Material Flammability Rating：-
Insulation Color：-
Current Rating (Amps)：-
Voltage Rating：-

Headers, Male Pins datasheet and documents for TJC3-8AWJ UL (WT)

TJC3-8AWJ UL (WT)

Headers, Male Pins Overview

The TJC3-8AWJ UL (WT) is a bar connector manufactured by CWB Automotive Electronics Co., Ltd. It belongs to the TJC3 series, which utilizes a 2.5mm pitch design. The component supports applicable wire gauges ranging from AWG28# to AWG22#. It is rated for an operating temperature range of -25°C to 85°C and accommodates printed circuit board thicknesses between 1.2mm and 1.6mm. Electrical specifications include a voltage rating of 250V AC/DC and a current rating of 3A. Contact resistance is specified at ≤0.01Ω, with insulation resistance ≥1000MΩ and a withstand voltage of 1000V AC/minute.

Headers, Male Pins Feature Summary

Utilizes a crimp-style connection mechanism for secure terminal attachment.
Features a 2.5mm pitch bar connector design for standardized spacing.
Complies with UL safety standards for electrical components.

Headers, Male Pins Applications

Automotive electronic systems
Active safety module connections
Power steering module interfaces

Headers, Male Pins Procurement Notes

Verify that the specific ordering suffix matches the required configuration, as variations may exist within the TJC3 series. Confirm that the supplier provides official documentation confirming UL certification status. Ensure compatibility with the target PCB thickness and wire gauge requirements before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this component when a 2.5mm pitch bar connector is required for automotive applications. Ensure the design accommodates the specified 3A current rating and 250V voltage limit. Verify that the operating environment falls within the -25°C to 85°C temperature range. Confirm that the application requires a crimp-type termination method.

Headers, Male Pins Part Context

This part is produced by CWB Automotive Electronics Co., Ltd, a manufacturer specializing in automotive electronics connectors. The company produces various bar connectors with different pitches, including 1.0mm, 1.25mm, 1.5mm, 2.0mm, 2.2mm, and 2.5mm options. The TJC3 series represents their 2.5mm pitch product line designed for automotive use.

Headers, Male Pins Replacement Considerations

Publicly confirmed substitute part numbers are not available in the provided source material. Cross-reference with other 2.5mm pitch bar connectors only if official substitution data is obtained from the manufacturer.
