TLP190B(C20TL,UC,F

Description：OPTOISO 2.5KV 1CH PHVOLT 6-MFSOP
Series：-
Mfr：Toshiba Semiconductor and Storage
Package：Bulk

SKU:d38a690eed20 Category: Transistor, Photovoltaic Output Optoisolators Brand: Toshiba Semiconductor and Storage

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：OPTOISO 2.5KV 1CH PHVOLT 6-MFSOP
Series：-
Mfr：Toshiba Semiconductor and Storage
Package：Bulk
Number of Channels：1
Voltage - Isolation：2500Vrms
Current Transfer Ratio (Min)：-
Current Transfer Ratio (Max)：-
Turn On / Turn Off Time (Typ)：200µs, 1ms
Rise / Fall Time (Typ)：-
Input Type：DC
Output Type：Photovoltaic
Voltage - Output (Max)：8V
Current - Output / Channel：-
Voltage - Forward (Vf) (Typ)：1.4V
Current - DC Forward (If) (Max)：50 mA
Vce Saturation (Max)：-
Operating Temperature：-40°C ~ 85°C
Mounting Type：Surface Mount
Package / Case：6-SMD (4 Leads), Gull Wing
Supplier Device Package：6-MFSOP, 4 Lead

Download product information

TLP190B(C20TL,UC,F

Overview

The TLP190B(C20TL,UC,F) is a Toshiba photocopler featuring a GaAlAs infrared LED optically coupled to a photo-diode array with an integrated shunt resistor. It provides 2500Vrms isolation voltage and operates within a -40°C to 85°C temperature range. The device utilizes a mini flat package for surface mount assembly, designed specifically for MOS FET gate drive applications in telecommunication and programmable controller systems.

Feature Summary

Integrates a GaAlAs light emitting diode with a series-connected photo-diode array
Includes an internal shunt resistor suitable for direct MOS FET gate drive
Provides high voltage isolation between input and output circuits

Applications

MOS FET gate driver circuits
Telecommunication equipment signal isolation
Programmable controller interface isolation

Procurement Notes

Verify the specific suffix (C20TL,UC,F) against official Toshiba documentation to confirm exact packaging and binning specifications. Ensure the component meets RoHS compliance requirements for your target market. Cross-reference the manufacturer part number with authorized distributor catalogs to confirm current availability and authenticity before procurement.

Selection Notes

Select this component when a compact solution for driving MOS FET gates via optical isolation is required. The integrated shunt resistor simplifies circuit design by eliminating external components. Consider the 2500Vrms isolation rating and operating temperature range to ensure compatibility with the system's electrical and environmental constraints.

Part Context

This component belongs to Toshiba's mini flat coupler series, designed for surface mount assembly. It represents a specialized category of optocouplers that combine light emission and detection with passive resistance for power control applications. The series is widely used in industrial automation and communication infrastructure where reliable galvanic isolation is critical for signal integrity.
