TLW-109-05-T-D

Headers, Male Pins Overview

The TLW-109-05-T-D is a 2-row pin header from Samtec's Flex Stack TLW series, designed for board-to-board or cable interconnections. It features 18 positions with a 2.54 mm (0.1 in) pitch and straight through-hole mounting. The connector utilizes tin-plated phosphor bronze contacts housed in black liquid crystal polymer (LCP). It supports a maximum current rating of 5.2 A and operates within a temperature range of -55°C to +105°C.

Headers, Male Pins Feature Summary

• Low profile terminal strip design for compact stacking applications
• Flexible mating post system accommodates various socket heights
• Tin-plated phosphor bronze contacts ensure reliable conductivity

Headers, Male Pins Applications

• Board-to-Board interconnects
• Cable connections
• High-density electronic assemblies

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix to confirm contact plating and termination style. Ensure the selected variant matches the required stack height and current carrying capacity for the target application. Confirm RoHS compliance status if restricted substances are a constraint. Cross-reference the ECAD model for accurate footprint integration.

Headers, Male Pins Selection Notes

Select this component when a low-profile, double-row header is required for rigid PCB connections. Consider the .025 inch square post system for compatibility with Samtec sockets. Evaluate thermal requirements against the -55°C to +105°C operating range. Choose alternative series if right-angle mounting or different pitch specifications are necessary.

Headers, Male Pins Part Context

This part belongs to the TLW series, characterized by low-profile terminal strips. It is distinct from the SSW series which features socket strips. The TLW series is optimized for vertical stacking and direct board-to-board connections using standard pin headers.

Headers, Male Pins Replacement Considerations

Compatible mating products include SSQ-109-02-S-D-RA and TSW-109-05-T-D. Verify mechanical fit and electrical ratings before substituting with other Samtec headers or third-party equivalents.
