TMM-103-04-S-S

Headers, Male Pins Overview

The TMM-103-04-S-S is a low-profile Tiger Eye header strip manufactured by Samtec Inc. It features a 2.00mm (0.079 inch) pitch with four positions in a single row. Designed for surface-mount installation, the connector utilizes phosphor bronze contacts with selective gold plating on the mating interface and matte tin on the tail. The housing is constructed from black liquid crystal polymer (LCP) rated UL94 V-0. It supports board-to-board or cable applications within an operating temperature range of -55°C to 125°C.

Headers, Male Pins Feature Summary

• Low-profile design optimized for space-constrained surface-mount applications
• Selective gold plating ensures reliable signal transmission at contact points
• Flexible pin structure accommodates minor misalignments during assembly

Headers, Male Pins Applications

• Board-to-board interconnections
• Cable-to-board connections
• High-density electronic assemblies

Headers, Male Pins Procurement Notes

Verify that the specific suffix matches the required termination style and plating configuration. Confirm that the selected variant aligns with the target PCB footprint and mounting orientation. Ensure compliance with RoHS directives if required by the end product specifications.

Headers, Male Pins Selection Notes

Select this component when a compact, high-reliability connection is needed for dense layouts. The flexible pin design aids in reducing insertion force and preventing damage during mating. Evaluate thermal requirements against the specified operating temperature range before finalizing the design.

Headers, Male Pins Part Context

This part belongs to the TMM series of low-profile header strips. The series is characterized by its flexible pin technology and robust construction suitable for demanding environments. It serves as a standard interconnect solution for modern electronics requiring small form factors.
