TMM-106-01-S-D-SM-A-P-TR

Headers, Male Pins Overview

The TMM-106-01-S-D-SM-A-P-TR is a board-to-board connector from the Samtec TMM series, designed for surface mount termination. It features a dual-row configuration with 11 total contacts arranged in two rows of five plus one polarizing pin. The connector utilizes a 2.00mm (0.079 inch) mating pitch and square contact shapes. Contacts are made of phosphor bronze with gold plating on the mating interface and matte tin on the tail. The housing is constructed from black liquid crystal polymer (LCP), rated UL94 V-0, supporting an operating temperature range of -55°C to 125°C.

Headers, Male Pins Feature Summary

• Surface mount design with integrated pick-and-place pads for automated assembly
• Polarized structure ensures correct orientation during mating
• Push-pull locking mechanism provides secure retention

Headers, Male Pins Applications

• Board-to-board interconnections in compact electronic modules
• High-density signal routing in telecommunications equipment
• Interfacing between daughterboards and motherboards in industrial control systems

Headers, Male Pins Procurement Notes

Verify that the specific suffixes match the required termination type and polarization. Confirm RoHS compliance status aligns with project requirements. Ensure the reel packaging matches the intended surface mount process capabilities. Cross-reference the datasheet for exact footprint dimensions to validate PCB layout compatibility before final procurement.

Headers, Male Pins Selection Notes

Select this component when a low-profile, surface-mount solution with high reliability is required. The TMM series offers a balance of density and mechanical stability. Consider the push-pull feature if vibration resistance is critical. Evaluate the 2.00mm pitch against available board space constraints compared to finer pitch alternatives.

Headers, Male Pins Part Context

This part belongs to the Tiger Eye™ TMM family, known for its robust construction and versatile mounting options. The TMM series supports both through-hole and surface mount configurations. The specific model indicates a standard length variant within the 106 series, offering a reliable connection point for dense circuit architectures.

Headers, Male Pins Replacement Considerations

Direct substitutes may include other Samtec TMM variants with identical pitch and row count but different termination or polarization. Verify that any alternative maintains the same contact material and plating specifications to ensure electrical performance equivalence.
