TMM-106-01-T-D-SM

Headers, Male Pins Overview

Samtec Inc. TMM-106-01-T-D-SM is a surface mount header strip featuring a 2.00mm pitch and 12 positions across two rows. Constructed with phosphor bronze contacts and liquid crystal polymer insulation, it supports a rated current of 3.2A per contact. The component operates within a temperature range of -55°C to 105°C and utilizes tin plating on both mating and termination surfaces.

Headers, Male Pins Feature Summary

• Low profile design for compact board-to-board or cable interconnections
• Polarized keying features ensure correct alignment during assembly
• Robust construction using LCP insulation and tin-plated phosphor bronze contacts

Headers, Male Pins Applications

• Board-to-board interconnects
• Cable to board connections
• General purpose electronic assemblies requiring low profile headers

Headers, Male Pins Procurement Notes

Verify the specific suffix against official Samtec documentation to confirm exact pin count and orientation. Ensure compatibility with automated surface mount placement equipment. Confirm RoHS compliance status through the manufacturer's latest datasheet before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this component when a low-profile, polarized surface mount header is required. It suits applications needing reliable electrical connections in space-constrained environments. Verify that the 2.00mm pitch aligns with the target PCB footprint and mating connector specifications.

Headers, Male Pins Part Context

This part belongs to the TMM series of low profile Tiger Eye header strips. These connectors are designed for high-density applications where vertical space is limited. The series offers various configurations to meet diverse interconnection needs in modern electronics manufacturing.

Headers, Male Pins Replacement Considerations

Check for direct substitutes within the TMM family with identical pitch and row configuration. Verify mechanical dimensions and electrical ratings match the original design requirements before considering alternative part numbers.
