TMM-114-04-T-D-SM

Headers, Male Pins Overview

The TMM-114-04-T-D-SM is a board connector from the Samtec TMM series, featuring 28 contacts arranged in two rows with a 2 mm pitch. It utilizes male pin terminals designed for surface mount installation. The connector employs phosphor bronze contacts with tin plating and an LCP black insulator. It supports a rated current of 3.2 A per contact and operates within a temperature range of -55°C to 125°C.

Headers, Male Pins Feature Summary

• Low-profile design optimized for space-constrained PCB layouts
• Push-pull fastening mechanism ensures secure mating retention
• Surface mount termination facilitates automated assembly processes

Headers, Male Pins Applications

• Board-to-board interconnects in compact electronic modules
• High-density signal routing in consumer electronics
• Industrial control systems requiring reliable surface mount connections

Headers, Male Pins Procurement Notes

Verify the specific suffix codes against official Samtec documentation to confirm exact plating thickness, reel specifications, and polarized features. Ensure the selected variant matches the required thermal profile for surface mount reflow processes. Cross-reference the full part number to distinguish between standard and specialized configurations.

Headers, Male Pins Selection Notes

Select this component when a low-profile, high-density connection is required for surface mount applications. The 2 mm pitch allows for compact designs while maintaining robust mechanical stability. Consider the push-pull feature for applications needing secure retention without soldering the mating interface directly.

Headers, Male Pins Part Context

This part belongs to the Tiger Eye™ TMM series, characterized by its low-profile header strips. The series is engineered for rugged board-to-board interconnects, offering reliability in demanding environments. The TMM-114 variant specifically provides a 28-position configuration suitable for dense signal routing.

Headers, Male Pins Replacement Considerations

Consult Samtec's official substitution guide for verified equivalents. Generic replacements may not match the precise 2 mm pitch or push-pull retention mechanics. Verify compatibility with existing PCB footprints and mating connector profiles before implementation.
