TMM-118-01-S-D

Headers, Male Pins Overview

The Samtec TMM-118-01-S-D is a low-profile terminal strip header featuring a 2.00 mm (0.079 in) pitch and 36 positions arranged in two rows. Designed for through-hole mounting, it utilizes gold-plated phosphor bronze contacts with a matte tin termination finish. The connector supports a current rating of 3.2 A per contact and withstands voltages up to 350 V. Constructed with liquid crystal polymer insulation rated UL 94 V-0, it operates reliably within a temperature range of -55°C to +125°C.

Headers, Male Pins Feature Summary

• Low-profile design optimized for space-constrained board-to-board applications
• Tiger Eye interconnect system ensures secure push-pull retention
• Gold-plated contacts provide reliable signal transmission
• Straight through-hole termination facilitates standard PCB assembly

Headers, Male Pins Applications

• Board-to-board interconnections
• Cable-to-board connections
• Mezzanine circuit architectures

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix against official Samtec documentation to confirm exact pin count, plating thickness, and termination style. Ensure the selected variant matches the required PCB footprint and mating interface specifications before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this component when a 2.00 mm pitch male header is required for high-density layouts. Confirm that the 3.2 A current rating and 350 V voltage limit align with the target application's electrical requirements and thermal management capabilities.

Headers, Male Pins Part Context

This part belongs to the TMM series of Tiger Eye terminal strips, designed for rugged board-to-board connectivity. It complements matching socket strips like the SMM series to form complete interconnect systems suitable for demanding industrial and commercial environments.

Headers, Male Pins Replacement Considerations

Compatible substitutes include the SMM-118-01-S-D socket counterpart or other TMM series headers with identical 2.00 mm pitch and 36-position configurations.
