TMM-122-01-S-Q-RA

$10.50

Description：2MM TERMINAL STRIP
Series：TMM
Mfr：Samtec Inc.
Package：Tube

SKU:ba9f625435f2 Category: Headers, Male Pins Brand: Samtec Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

TMM-122-01-S-Q-RA is listed in the Headers, Male Pins range at ChipApex. The manufacturer field lists Samtec Inc.. Its product description is 2MM TERMINAL STRIP. Review the specifications below when checking this part for your BOM.

Headers, Male Pins specifications for TMM-122-01-S-Q-RA

Description：2MM TERMINAL STRIP
Series：TMM
Mfr：Samtec Inc.
Package：Tube
Connector Type：Header
Contact Type：Male Pin
Pitch - Mating：0.079" (2.00mm)
Number of Positions：88
Number of Rows：4
Row Spacing - Mating：0.079" (2.00mm)
Number of Positions Loaded：All
Style：Board to Board or Cable
Shrouding：Unshrouded
Mounting Type：Through Hole, Right Angle
Termination：Solder
Fastening Type：Push-Pull
Contact Length - Mating：0.126" (3.20mm)
Contact Length - Post：0.120" (3.05mm)
Overall Contact Length：-
Insulation Height：0.315" (8.00mm)
Contact Shape：Square
Contact Finish - Mating：Gold
Contact Finish Thickness - Mating：30.0µin (0.76µm)
Contact Finish - Post：Tin
Contact Material：Phosphor Bronze
Insulation Material：Liquid Crystal Polymer (LCP)
Features：-
Operating Temperature：-55°C ~ 125°C
Ingress Protection：-
Material Flammability Rating：-
Insulation Color：Black
Current Rating (Amps)：3.2A per Contact
Voltage Rating：-

Headers, Male Pins datasheet and documents for TMM-122-01-S-Q-RA

TMM-122-01-S-Q-RA

Headers, Male Pins Overview

The TMM-122-01-S-Q-RA is a board connector featuring 43 contacts arranged in two rows. It utilizes male phosphor bronze terminals with gold flash plating on the mating interface and matte tin termination. The component employs a 2 mm terminal pitch and is designed for surface mount installation. Key specifications include a straight orientation, polarized construction, and compliance with RoHS standards.

Headers, Male Pins Feature Summary

Polarized design ensures correct alignment during assembly
Gold flash plating provides reliable signal conductivity
Surface mount termination facilitates automated PCB placement

Headers, Male Pins Applications

General purpose board-to-board interconnects
High-density electronic assemblies requiring precise alignment

Headers, Male Pins Procurement Notes

Verify the specific suffix configuration against official Samtec documentation to confirm exact contact count and plating thickness. Ensure compatibility with mating connectors regarding polarization keys and row spacing. Cross-reference datasheet revisions to validate current manufacturing status and environmental compliance certifications prior to final procurement.

Headers, Male Pins Selection Notes

Select this component when a low-profile, polarized surface mount header is required for dense circuit layouts. The 2 mm pitch offers a balance between pin density and mechanical stability. Verify that the mating connector supports the specified gold flash finish and matches the straight mounting orientation for optimal board integration.

Headers, Male Pins Part Context

This part belongs to the TMM series of low-profile through-hole and surface mount headers manufactured by Samtec Inc. The series is characterized by its flexible stacking capabilities and robust mechanical design suitable for various industrial applications. The specific model denotes a double-row configuration with right-angle or straight mounting options depending on the suffix.
