TMM-127-01-S-S-SM

Headers, Male Pins Overview

The TMM-127-01-S-S-SM is a low-profile board-to-board header manufactured by Samtec Inc. It features a single row of 27 male pin contacts with a 2.00mm (0.079 inch) pitch. Designed for surface mount installation, the connector utilizes phosphor bronze contacts with a gold plating finish on the mating interface and matte tin on the termination side. The housing is constructed from black liquid crystal polymer (LCP), rated for operation between -55°C and 125°C. Each contact supports a current rating of 3.2A, ensuring reliable electrical performance in compact electronic assemblies.

Headers, Male Pins Feature Summary

• Low-profile design suitable for space-constrained applications
• Gold-plated contacts ensure reliable signal transmission
• Surface mount terminal configuration for automated assembly

Headers, Male Pins Applications

• Board-to-board interconnects
• Compact electronic device assembly
• High-density circuit board connections

Headers, Male Pins Procurement Notes

Verify that the specific suffixes match the required mounting style and contact count. Confirm RoHS compliance status if environmental regulations apply to the final product. Ensure the supplier provides official datasheets for dimensional verification before integration into the design.

Headers, Male Pins Selection Notes

Select this component when a single-row, surface-mount header with a 2mm pitch is required. Consider the 3.2A current rating and temperature range against system requirements. Compare physical dimensions with available PCB real estate to ensure proper fit.

Headers, Male Pins Part Context

This part belongs to the TMM series of low-profile Tiger Eye headers. The series offers various configurations including through-hole and surface mount options with different row counts and contact materials. This specific model represents a standard single-row variant optimized for vertical board stacking.

Headers, Male Pins Replacement Considerations

Parts like TMM-127-01-S-S-RA-016 may serve as alternatives if mechanical rotation or legacy footprint compatibility is needed. Verify exact pin count and pitch alignment before substitution.
