TMPF 0605A-3R3MN-ABD

TMPF 0605A-3R3MN-ABD is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists TAI-TECH Advanced Electronics Co., Ltd.. Its product description is 3.3 UH SHIELDED MOLDED INDUCTOR. Review the specifications below when checking this part for your BOM.

Fixed Inductors specifications for TMPF 0605A-3R3MN-ABD

• Description：3.3 UH SHIELDED MOLDED INDUCTOR
• Series：TMPF0605A-ABD
• Mfr：TAI-TECH Advanced Electronics Co., Ltd.
• Package：Tape & Reel (TR)
• Type：-
• Material - Core：-
• Inductance：3.3 µH
• Tolerance：±20%
• Current Rating (Amps)：8.5 A
• Current - Saturation (Isat)：10A
• Shielding：Unshielded
• DC Resistance (DCR)：5.7mOhm Max
• Q @ Freq：-
• Frequency - Self Resonant：-
• Ratings：-
• Operating Temperature：-55°C ~ 150°C
• Inductance Frequency - Test：100 kHz
• Mounting Type：Surface Mount
• Package / Case：0605 (1613 Metric)
• Supplier Device Package：605
• Size / Dimension：0.260" L x 0.252" W (6.60mm x 6.40mm)
• Height - Seated (Max)：0.197" (5.00mm)
• Features：-

Fixed Inductors datasheet and documents for TMPF 0605A-3R3MN-ABD
