TND14SV681KTLBPAA0 is listed in the Varistors, MOVs range at ChipApex. The manufacturer field lists Chemi-Con. Its product description is VARISTOR 680V 5KA DISC 14MM. Review the specifications below when checking this part for your BOM.
Varistors, MOVs specifications for TND14SV681KTLBPAA0
- Description：VARISTOR 680V 5KA DISC 14MM
- Series：SV
- Mfr：Chemi-Con
- Package：Cut Tape (CT),Tape & Box (TB)
- Maximum AC Volts：420 V
- Maximum DC Volts：560 V
- Varistor Voltage (Min)：612 V
- Varistor Voltage (Typ)：680 V
- Varistor Voltage (Max)：748 V
- Current - Surge：5 kA
- Energy：136J
- Number of Circuits：1
- Capacitance @ Frequency：310 pF @ 1 kHz
- Operating Temperature：-40°C ~ 125°C (TA)
- Mounting Type：Through Hole
- Package / Case：Disc 14mm
- Grade：Automotive
- Qualification：AEC-Q200
- Features：-
