TPCB02593-12-AM-AGDP-L

Antennas RF Overview

The Nearson TPCB02593-12-AM-AGDP-L is an embedded microstrip radio frequency antenna designed for printed circuit board integration. It operates with a right-angle MMCX connector interface, providing reliable signal transmission in compact form factors. The component supports dual-band functionality covering the 824 MHz to 960 MHz range and the 1.71 GHz to 1.99 GHz range. It features a nominal gain of 0 dBi, ensuring standard radiation characteristics suitable for various wireless communication applications requiring space-efficient antenna solutions.

Antennas RF Feature Summary

• Embedded microstrip design optimized for direct PCB mounting
• Right-angle MMCX connector interface for secure attachment
• Dual-band operation supporting sub-GHz and cellular frequencies

Antennas RF Applications

• Wireless sensor networks
• IoT device connectivity modules
• Mobile communication hardware

Antennas RF Procurement Notes

Verify the specific ordering suffix against official Nearson documentation to confirm connector type and material specifications. Ensure compatibility with target RF circuit impedance requirements before procurement. Cross-reference the part number with authorized distributors to validate authenticity and current manufacturing status. Confirm RoHS compliance details if environmental regulations apply to the final assembly process.

Antennas RF Selection Notes

Select this component when a low-profile, embedded antenna solution is required for devices operating within the specified frequency bands. The right-angle MMCX interface facilitates easy integration into tight mechanical enclosures. Consider the 0 dBi gain profile for applications where omnidirectional coverage is sufficient without high-gain directional requirements. Evaluate PCB layout constraints to ensure optimal antenna performance based on the embedded microstrip design.

Antennas RF Part Context

This model belongs to the Nearson TPCB02593 series of embedded antennas. The series offers various configurations tailored for different connector types and frequency ranges. The TPCB02593-12-AM-AGDP-L variant specifically utilizes the MMCX interface and targets dual-band wireless applications. It represents a standardized solution for integrating RF capabilities into compact electronic systems without compromising structural integrity.

Antennas RF Replacement Considerations

Direct substitutes may include other Nearson embedded microstrip antennas with compatible connector interfaces and overlapping frequency ranges. Verify mechanical dimensions and impedance matching when considering alternative models from different manufacturers. Ensure that any replacement maintains the required right-angle orientation and embedding capabilities for the specific application environment.
