TPMR6G

Single Diodes Overview

The TPMR6G is a super fast recovery rectifier diode manufactured by Taiwan Semiconductor Corporation. It features a 6 A average forward current rating and is housed in the TO-277A (SMPC) surface mount package. The device utilizes an epitaxial planar structure with a glass passivated junction for reliability. Key electrical characteristics include a maximum repetitive peak reverse voltage of 400 V and a typical reverse recovery time of 35 ns, ensuring high efficiency in switching applications.

Single Diodes Feature Summary

• Super fast recovery performance optimized for high-frequency switching
• Glass passivated junction chip providing enhanced stability
• Epitaxial planar construction for robust operation
• Low profile surface mount design suitable for automated placement

Single Diodes Applications

• High frequency DC/DC converters
• Free wheeling rectification in power supplies
• Polarity protection circuits
• Snubber circuits

Single Diodes Procurement Notes

Verify the specific suffix and packaging configuration when ordering to ensure compatibility with automated assembly lines. Confirm RoHS compliance status and lead times directly with authorized distributors or the manufacturer, as availability may vary by region and production batch.

Single Diodes Selection Notes

Select this component for applications requiring rapid switching speeds and moderate current handling in a compact surface mount footprint. Ensure the circuit's reverse voltage requirements do not exceed the 400 V rating and that thermal management supports the 6 A continuous current capability within the specified operating temperature range.

Single Diodes Part Context

This part belongs to the super fast recovery rectifier series from Taiwan Semiconductor. It is designed to replace standard recovery diodes in applications where reduced reverse recovery charge and faster switching times are critical for improving overall system efficiency and reducing electromagnetic interference.

Single Diodes Replacement Considerations

Direct replacements must match the 6 A current rating, 400 V reverse voltage, and TO-277A (SMPC) package. Verify that substitute components offer comparable reverse recovery time specifications to maintain circuit performance.
