TPS62301YZDR is listed in the Voltage Regulators - DC DC Switching Regulators range at ChipApex. The manufacturer field lists Texas Instruments. Its product description is IC REG BUCK 1.5V 500MA 8DSBGA. Review the specifications below when checking this part for your BOM.
Voltage Regulators - DC DC Switching Regulators specifications for TPS62301YZDR
- Description：IC REG BUCK 1.5V 500MA 8DSBGA
- Series：-
- Mfr：Texas Instruments
- Package：Tape & Reel (TR),Bulk
- Function：Step-Down
- Output Configuration：Positive
- Topology：Buck
- Output Type：Fixed
- Number of Outputs：1
- Voltage - Input (Min)：2.7V
- Voltage - Input (Max)：6V
- Voltage - Output (Min/Fixed)：1.5V
- Voltage - Output (Max)：-
- Current - Output：500mA
- Frequency - Switching：3MHz
- Synchronous Rectifier：Yes
- Operating Temperature：-40°C ~ 85°C (TA)
- Mounting Type：Surface Mount
- Package / Case：8-UFBGA, DSBGA
- Supplier Device Package：8-DSBGA
- Grade：-
- Qualification：-
Voltage Regulators - DC DC Switching Regulators datasheet and documents for TPS62301YZDR
Voltage Regulators - DC DC Switching Regulators Overview
The TPS62301YZDR is a synchronous step-down converter from Texas Instruments, housed in an 8-DSBGA package. It delivers a fixed 1.5 V output at up to 500 mA. The device operates with an input voltage range of 2.7 V to 6 V and features a 3 MHz switching frequency. It supports shutdown functionality and functions within a temperature range of -40°C to +85°C.
Voltage Regulators - DC DC Switching Regulators Feature Summary
- Synchronous buck topology for high efficiency
- Fixed 1.5 V output voltage configuration
- Compact chip-scale packaging design
Voltage Regulators - DC DC Switching Regulators Applications
- Portable battery-powered equipment
- Embedded systems power management
- Industrial control modules
Voltage Regulators - DC DC Switching Regulators Procurement Notes
Verify component authenticity through authorized channels. Confirm the obsolete status and availability of substitutes like the TPS62301DRCR. Ensure compliance with RoHS standards and check moisture sensitivity levels before storage and assembly processing.
Voltage Regulators - DC DC Switching Regulators Selection Notes
Select this part for applications requiring a fixed 1.5 V rail from a 2.7 V to 6 V source. The 500 mA current capability suits low-power loads. Consider the 8-DSBGA package constraints for thermal management and PCB layout requirements during integration.
Voltage Regulators - DC DC Switching Regulators Part Context
This component belongs to the TPS6230x series of synchronous step-down converters. It shares architectural similarities with other members like the TPS62300 but differs in output voltage configuration and specific package variants. It serves as a compact power solution within Texas Instruments' PMIC portfolio.
Voltage Regulators - DC DC Switching Regulators Replacement Considerations
The TPS62301YZDR is obsolete. The TPS62301DRCR is listed as a similar available substitute. Verify pin compatibility and electrical specifications before substitution.
