TPS7A0512PYKAR

Voltage Regulators - Linear, Low Drop Out (LDO) Regulators Overview

The TPS7A0512PYKAR is a fixed-output linear low-dropout (LDO) voltage regulator manufactured by Texas Instruments. It provides a stable 1.2V output with a maximum continuous current of 200mA. The device features an ultra-low quiescent current of 3µA and supports input voltages up to 5.5V. It incorporates comprehensive protection mechanisms including overcurrent, thermal overload, and under-voltage lockout (UVLO). The regulator offers a typical power supply rejection ratio (PSRR) of 40dB across the 1kHz to 1MHz frequency range. It operates within a junction temperature range of -40°C to 125°C and utilizes a compact 4-DSBGA package for surface-mount applications.

Voltage Regulators - Linear, Low Drop Out (LDO) Regulators Feature Summary

• Ultra-low quiescent current consumption for extended battery life in portable devices
• Integrated protection functions including overcurrent limiting, thermal shutdown, and UVLO
• High power supply rejection ratio ensuring clean output voltage regulation
• Fixed 1.2V output configuration simplifying circuit design

Voltage Regulators - Linear, Low Drop Out (LDO) Regulators Applications

• Battery-powered consumer electronics requiring efficient power management
• Portable medical equipment needing stable low-noise voltage supplies
• Wearable technology utilizing space-constrained surface-mount packages
• IoT sensor nodes operating on limited energy sources

Voltage Regulators - Linear, Low Drop Out (LDO) Regulators Procurement Notes

Verify the specific suffix 'PYKAR' corresponds to the 4-DSBGA package and tape-and-reel orientation as defined in the official datasheet. Confirm that the 1.2V fixed output matches the target system requirements. Ensure compatibility with RoHS3 standards and check for any recent packaging or marking changes via official Texas Instruments product change notifications before finalizing procurement orders.

Voltage Regulators - Linear, Low Drop Out (LDO) Regulators Selection Notes

Select this component when a fixed 1.2V rail is required with minimal static power draw. The 200mA output capability suits moderate load applications. Consider the 4-DSBGA footprint for PCB space optimization. Evaluate the 5.5V maximum input rating against the source voltage. Verify thermal performance at full load given the small package size and ensure adequate board copper area for heat dissipation.

Voltage Regulators - Linear, Low Drop Out (LDO) Regulators Part Context

This part belongs to the TPS7A05 series of ultra-low-IQ LDO regulators from Texas Instruments. The series includes various output voltage options and package types such as SOT-23-5 and X2SON. The TPS7A0512PYKAR specifically denotes the 1.2V variant in the 4-DSBGA form factor. It shares core architectural features like high PSRR and protection circuits with other members of the family while differing in output voltage and physical dimensions.
