TPV-H25HM50RNC-27.000M

Oscillators Overview

The TPV-H25HM50RNC-27.000M is a Voltage-Controlled Crystal Oscillator (VCXO) manufactured by Transko Electronics, Inc., operating at a nominal frequency of 27.0000 MHz. It utilizes an HCMOS output signal and requires a maximum supply current of 55 mA. The device exhibits a frequency stability of ±25 ppm and an Absolute Pull Range (APR) of ±100 ppm. It is designed for operation within a temperature range of 0°C to 70°C.

Oscillators Feature Summary

• Voltage-controlled crystal oscillator architecture enabling frequency tuning
• HCMOS digital output interface for logic compatibility
• Supports absolute pull range adjustment via control voltage

Oscillators Applications

• Clock generation in communication systems requiring frequency agility
• Data transmission equipment needing precise timing references
• Test and measurement instruments utilizing stable oscillators

Oscillators Procurement Notes

Verify the specific package configuration against official documentation, as sources indicate potential variations such as SOJ-4 or SMD formats. Confirm that the required supply voltage aligns with the component's electrical specifications before integration. Ensure the application environment remains within the specified 0°C to 70°C operating temperature range to maintain guaranteed frequency stability and performance metrics.

Oscillators Selection Notes

Select this component when a voltage-controlled frequency adjustment is required rather than a fixed-frequency standard XO. The HCMOS output simplifies interfacing with digital logic circuits without additional buffering. Consider the ±100 ppm APR limit when designing the tuning circuit to ensure the desired frequency deviation can be achieved within the available control voltage range.

Oscillators Part Context

This part belongs to the VCXO category from Transko Electronics, Inc., distinct from their standard XO lines like the TSM32 series. While sharing similar output types, the TPV series specifically incorporates voltage control capabilities for dynamic frequency adjustment, differentiating it from fixed-frequency oscillators used in static clock applications.

Oscillators Replacement Considerations

Publicly confirmed substitute part numbers are not available in the provided documentation. Cross-reference with other Transko VCXO models only if pinout and electrical parameters match exactly.
