TRAB24003NP

Antennas RF Overview

The TE Connectivity TRAB24003NP is a passive omnidirectional dome antenna designed for outdoor wireless applications. Operating within the 2.4 GHz to 2.5 GHz frequency range, it features a vertical polarization and N female connector interface. The unit provides 3 dBi gain with a maximum power rating of 100 W and a VSWR of 2.1. It utilizes an NMO mount style for installation and measures 2.75 inches in length. This component supports protocols including Bluetooth, Wi-Fi, WLAN, Zigbee, and ANT.

Antennas RF Feature Summary

• Omnidirectional radiation pattern suitable for broad coverage applications
• Passive construction with high power handling capability
• Durable dome design intended for permanent outdoor deployment

Antennas RF Applications

• GSM and Wi-Fi wireless networks
• Bluetooth and BLE communications
• Zigbee and Thread IoT deployments
• WLAN infrastructure systems

Antennas RF Procurement Notes

Verify the specific suffix configuration against project requirements to ensure compatibility with existing mounting hardware and connector types. Confirm that the NMO base requirement aligns with the installation surface specifications. Check RoHS compliance status if environmental regulations apply to the deployment site. Ensure the 100 W power rating exceeds the transmitter output to prevent damage. Validate the frequency range matches the operational band of the connected radio equipment.

Antennas RF Selection Notes

Select this model when a compact, low-profile dome antenna is required for 2.4 GHz ISM band operations. It is appropriate for installations where aesthetic integration or wind load reduction is prioritized over high-gain directional performance. Consider the NMO mounting interface for secure attachment to metal surfaces. Evaluate the 3 dBi gain as sufficient for general coverage rather than long-range point-to-point links.

Antennas RF Part Context

This component belongs to the Phantom series of antennas from TE Connectivity. The series includes various configurations for different mounting styles and connector types. The TRAB24003NP specifically denotes the variant with an N female connector and NMO base. It is categorized under outdoor passive antennas designed for robust environmental performance.

Antennas RF Replacement Considerations

TRA24003CM and TRAB24003 are listed as parameter-equivalent substitutes. Verify connector type and mounting interface differences before substitution. TRA24003CM may differ in connector configuration. TRAB24003 lacks the NP suffix, indicating potential variation in color or material finish.
