TRI 20-4822

TRI 20-4822 is listed in the DC DC Converters range at ChipApex. The manufacturer field lists Traco Power. Its product description is DC DC CONVERTER +/-12V 20W. Review the specifications below when checking this part for your BOM.

DC DC Converters specifications for TRI 20-4822

• Description：DC DC CONVERTER +/-12V 20W
• Series：TRI 20 (20W)
• Mfr：Traco Power
• Package：Tube
• Type：Isolated Module
• Number of Outputs：2
• Voltage - Input (Min)：36V
• Voltage - Input (Max)：75V
• Voltage - Output 1：12V
• Voltage - Output 2：-12V
• Voltage - Output 3：-
• Voltage - Output 4：-
• Current - Output (Max)：840mA, 840mA
• Power (Watts)：20 W
• Voltage - Isolation：8 kV
• Applications：ITE (Commercial)
• Features：-
• Operating Temperature：-40°C ~ 76°C
• Efficiency：89%
• Mounting Type：Through Hole
• Package / Case：5-DIP Module
• Size / Dimension：2.00" L x 1.00" W x 0.47" H (50.8mm x 25.4mm x 12.0mm)
• Supplier Device Package：-
• Control Features：-
• Approval Agency：CB, cURus
• Standard Number：-
• Grade：-
• Qualification：-

DC DC Converters datasheet and documents for TRI 20-4822
