TS.07.0113

Antennas RF Overview

The TS.07.0113 is a passive GPS/GLONASS/GALILEO/BeiDou terminal antenna manufactured by Taoglas Limited. It features a white monopole design with a rotatable hinge and an SMA male connector. The unit measures 72 mm in length and supports multi-constellation satellite navigation systems for vehicle tracking, telematics, and remote monitoring applications.

Antennas RF Feature Summary

• Multi-constellation support for GPS, GLONASS, GALILEO, and BeiDou
• Rotatable hinge design for flexible installation orientation
• Passive monopole construction with SMA male connector

Antennas RF Applications

• Vehicle tracking devices
• Telematics devices
• Remote monitoring systems

Antennas RF Procurement Notes

Verify the specific color variant required, as the TS.07 series includes both white (TS.07.0113) and orange options. Confirm that the SMA male connector type matches the host device interface. Ensure the 72 mm length fits within the mechanical constraints of the target assembly. Check current availability status as component lifecycles may change.

Antennas RF Selection Notes

Select this model when multi-constellation reception is required for satellite navigation. The rotatable hinge allows optimization of signal polarization relative to the receiver. Verify compatibility with GPS, GLONASS, GALILEO, and BeiDou bands. Ensure the SMA male connector aligns with the system's RF interface requirements.

Antennas RF Part Context

This component belongs to the TS.07 family of terminal antennas from Taoglas Limited. The series offers compact solutions for mobile and fixed installations requiring robust satellite positioning capabilities. The TS.07.0113 specifically denotes the white-colored variant with standard hinge mechanics.
