TSHS-103-S-08-A-G-LF

Headers, Male Pins Overview

The TSHS-103-S-08-A-G-LF is a board connector manufactured by Major League Electronics. It features 3 contacts arranged in a single row with male gender. The connector utilizes a straight orientation and a 0.1 inch pitch. It employs solder terminals for mounting. The insulator material is nylon, providing an insulation resistance of 1000000000 Ω. The component is lead-free compliant.

Headers, Male Pins Feature Summary

• Single row male header configuration
• Nylon insulator material
• Lead-free construction

Headers, Male Pins Applications

• General electronic board interconnections
• Signal transmission circuits
• Power distribution modules

Headers, Male Pins Procurement Notes

Verify the specific contact finish and plating thickness requirements against the official datasheet to ensure compatibility with mating connectors. Confirm that the lead-free designation aligns with environmental regulations applicable to the target assembly process. Check mechanical dimensions for proper fit within the designated enclosure space.

Headers, Male Pins Selection Notes

Select this component when a low-contact-count, single-row male header is required. Ensure the 0.1 inch pitch matches the PCB layout. Verify that the straight orientation fits the spatial constraints. Consider the nylon insulator properties for thermal and electrical performance needs.

Headers, Male Pins Part Context

This part belongs to the TSHS series of headers from Major League Electronics. The series offers various pin counts and configurations. This specific model represents a minimal contact option suitable for compact designs requiring reliable through-hole mounting.

Headers, Male Pins Replacement Considerations

Direct substitutes must match the 3-pin, single-row, male specification. Verify identical 0.1 inch pitch and straight orientation. Ensure compatible insulator materials and termination types are available from alternative manufacturers.
