TSHS-105-D-20-B-G-LF

Headers, Male Pins Overview

The TSHS-105-D-20-B-G-LF is a board connector manufactured by Major League Electronics. It features 10 contacts arranged in two rows with a male contact gender and straight mounting orientation. The component utilizes a 0.1 inch pitch and solder terminals for PCB attachment. It is classified as a receptacle with a black insulator. The part is lead-free compliant.

Headers, Male Pins Feature Summary

• Dual-row configuration for compact circuit integration
• Straight mounting style for standard board alignment
• Solder terminal design for secure PCB connection

Headers, Male Pins Applications

• General-purpose board-to-board interconnects
• Industrial control system signal routing
• Telecommunications equipment backplanes

Headers, Male Pins Procurement Notes

Verify the specific suffix codes against the manufacturer's official documentation to confirm exact plating thickness, insulation material properties, and compliance status. Ensure the ordering code matches the required pin count and row configuration before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this component when a dual-row, straight-mount board connector with a 0.1 inch pitch is required. Confirm that the solder termination method aligns with the assembly process and that the physical dimensions fit the designated footprint on the target printed circuit board.

Headers, Male Pins Part Context

This part belongs to the TSHS series of board connectors from Major League Electronics. The series offers various configurations including single and dual rows with different tail lengths and termination styles to accommodate diverse electronic assembly requirements.

Headers, Male Pins Replacement Considerations

Compatible substitutes include TSHS-105-D-20-A-G-LF and TSHS-105-D-20-B-G. Verify mechanical compatibility and electrical specifications before substitution.
