TSHS-110-D-06-A-H-LF

Headers, Male Pins Overview

The TSHS-110-D-06-A-H-LF is a board connector manufactured by Major League Electronics. It features 24 contacts arranged in two rows with a male configuration and straight orientation. The component utilizes a 0.1 inch pitch and solder terminals for mounting. It is designed as a receptacle type connector. The product complies with RoHS standards.

Headers, Male Pins Feature Summary

• Dual row male contact configuration
• Straight orientation design
• RoHS compliant construction

Headers, Male Pins Applications

• General electronic circuit interconnections
• Board-to-board signal transmission
• Industrial control system wiring

Headers, Male Pins Procurement Notes

Verify the specific pin count and terminal style against the official datasheet to ensure compatibility with the target PCB layout. Confirm that the soldering process parameters align with the component's thermal specifications. Check for any required mating connectors or accessories listed in the manufacturer documentation before finalizing the order.

Headers, Male Pins Selection Notes

Select this component when a dual row, 0.1 inch pitch male connector is required for straight board mounting. Ensure the application environment does not exceed the standard operating temperature range specified for nylon insulators. Verify that the contact plating options meet the corrosion resistance requirements of the intended use case.

Headers, Male Pins Part Context

This part belongs to the TSHS series of terminal strip headers from Major League Electronics. The series offers various configurations including single and dual rows with different pitch options. This specific model represents a standard lead-free variant within the lineup.

Headers, Male Pins Replacement Considerations

Compatible substitutes include TSHS-110-D-06-A-T-LF and TSHS-110-D-06-GT-SAD. Verify dimensional tolerances and terminal plating differences before substitution.
