TSHSM-103-D-02-H-H-TR-P-LF

Headers, Male Pins Overview

The TSHSM-103-D-02-H-H-TR-P-LF is a surface mount board connector manufactured by Major League Electronics. It features a dual row configuration with six contacts and a 0.100-inch (2.54mm) pitch. The component is designed as a male header with right-angle termination for PCB integration. It utilizes gold plating over nickel on the contact surfaces to ensure reliable electrical connectivity. The housing is constructed from thermoplastic material, providing structural stability and insulation. This part is RoHS compliant and intended for high-density electronic assemblies requiring secure surface-mounted connections.

Headers, Male Pins Feature Summary

• Surface mount technology implementation for automated PCB assembly
• Right-angle orientation facilitating compact circuit board layouts
• Gold-over-nickel contact plating for corrosion resistance
• Dual-row receptacle design supporting increased pin density

Headers, Male Pins Applications

• High-density consumer electronics interconnects
• Industrial control panel signal routing
• Telecommunications equipment board-to-board linking
• Automotive infotainment system module connections

Headers, Male Pins Procurement Notes

Verify that the specific ordering suffix matches the required post length and termination style. Confirm RoHS compliance status aligns with project environmental regulations. Ensure the right-angle orientation fits within the mechanical enclosure constraints. Check that the gold plating specification meets the required conductivity standards for the application environment.

Headers, Male Pins Selection Notes

Select this component when surface mounting is preferred over through-hole techniques to reduce profile height. Choose the right-angle variant to optimize spatial utilization in constrained vertical spaces. The dual-row format supports higher I/O counts within a limited footprint compared to single-row alternatives. Verify that the 0.100-inch pitch matches the mating connector specifications to ensure proper alignment and contact engagement.

Headers, Male Pins Part Context

This part belongs to the TSHSM series of surface mount headers from Major League Electronics. The series offers various row configurations and pitch options for diverse board layout needs. The TSHSM designation indicates a surface mount terminal strip with specific mechanical characteristics. It complements other MLE connector families by providing specialized mounting solutions for modern PCB designs.

Headers, Male Pins Replacement Considerations

Direct substitutes must match the 6-contact count, dual-row structure, and 0.100-inch pitch. Right-angle surface mount termination is critical for mechanical compatibility. Verify that alternative parts offer equivalent gold-over-nickel plating for similar performance. Ensure the replacement maintains the same RoHS compliance level if required by the manufacturing process.
