TSM-105-02-LM-SV-A-005-P

Headers, Male Pins Overview

The TSM-105-02-LM-SV-A-005-P is a surface mount terminal strip manufactured by Samtec Inc. It features a .100 inch (2.54 mm) pitch and utilizes .025 inch square post contacts. The connector has 5 positions arranged in a single row with male pin terminals. It employs split board lock technology for secure mounting. The insulator material is black liquid crystal polymer, and the contacts are phosphor bronze with gold plating on the mating interface.

Headers, Male Pins Feature Summary

• Features split board lock technology to ensure secure mechanical attachment during surface mount processing.
• Utilizes .025 inch square post contacts designed for high reliability and extended life cycles.
• Constructed with black liquid crystal polymer insulation for thermal stability and UL94 V-0 flammability rating.

Headers, Male Pins Applications

• Board-to-board interconnections requiring robust surface mount termination
• High-density electronic assemblies utilizing flexible stacking solutions
• Automotive A-Series product applications

Headers, Male Pins Procurement Notes

Verify the specific suffix codes against official Samtec documentation to confirm the presence of split board locks and gold plating specifications. Ensure the ordering configuration matches the required lead style and pick-and-place pad options. Cross-reference the RoHS compliance status and mating cycle ratings with current manufacturer data sheets before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this component when a surface mount header with split board locks is required for reliable assembly. The .025 inch square post design supports mating with various Samtec socket series. Consider the operating temperature range and voltage ratings relative to the system requirements. Verify that the single-row configuration fits within the available PCB footprint constraints.

Headers, Male Pins Part Context

This part belongs to the TSM series of surface mount terminal strips from Samtec. The series offers various row options and termination styles. The TSM-105-02-LM-SV-A-005-P specifically denotes a 5-position variant with light selective gold plating and split board lock features. It is designed for applications demanding high durability and precise surface mount placement.

Headers, Male Pins Replacement Considerations

Compatible mates include SSW, SSM, and HLE series headers. Verify pin compatibility and spacing before substituting with other Samtec products. Ensure the replacement part maintains the same surface mount termination and board lock requirements.
