TSM-106-01-S-SH-A-P

Headers, Male Pins Overview

The Samtec TSM-106-01-S-SH-A-P is a surface mount terminal strip featuring a 2.54 mm (0.100 inch) pitch and six positions in a single row. It utilizes phosphor bronze contacts with gold plating for mating surfaces and tin for termination posts. Designed for SMD/SMT installation, the connector supports a straight mounting angle and operates within a temperature range of -55°C to +125°C. The housing is constructed from black liquid crystal polymer (LCP) with UL 94 V-0 flammability rating.

Headers, Male Pins Feature Summary

• Designed specifically for surface mount applications with mixed technology pin options
• Features .025 inch square post terminals for reliable interconnection
• Supports high mating cycles and extended life performance standards

Headers, Male Pins Applications

• Automotive A-Series product integration
• High-speed data transmission up to 8 Gbps
• Board-to-board or cable connections requiring surface mount termination

Headers, Male Pins Procurement Notes

Verify the specific suffix configuration against official documentation to ensure correct pin style and termination type. Confirm RoHS compliance status and moisture sensitivity level requirements prior to ordering. Cross-reference the exact part number with manufacturer catalogs to validate current availability and packaging specifications.

Headers, Male Pins Selection Notes

Select this component when surface mount assembly is required for rigid interconnects. Ensure the board layout accommodates the specific footprint dimensions and reflow soldering profiles compatible with LCP insulation. Verify that the mating socket interface aligns with the .025 inch square post design for optimal contact retention.

Headers, Male Pins Part Context

This part belongs to the TSM series of flexible stacking solutions by Samtec. It provides a robust header option for dense circuit board layouts. The series offers various row configurations and pin styles to accommodate diverse mechanical constraints while maintaining electrical integrity in demanding environments.

Headers, Male Pins Replacement Considerations

TSM-106-01-L-SH-A-P serves as a potential alternative with different contact material properties. Verify mechanical compatibility and electrical ratings before substitution.
