TSM-108-01-T-DH

Headers, Male Pins Overview

The TSM-108-1-T-DH is a surface mount terminal strip from the Samtec TSM series. It features a single row of eight positions with a 0.100 inch (2.54 mm) pitch. The connector utilizes phosphor bronze contacts with tin plating and liquid crystal polymer insulation rated UL94 V-0. Designed for board-to-board or cable applications, it supports a temperature range of -55°C to 105°C.

Headers, Male Pins Feature Summary

• Surface mount design compatible with automated pick-and-place assembly processes
• Flexible stacking solution architecture allowing for variable height configurations
• Push-pull locking mechanism ensures secure mating retention

Headers, Male Pins Applications

• Board-to-board interconnections in compact electronic assemblies
• Cable-to-board connections requiring surface mount termination
• High-density signal routing in industrial control modules

Headers, Male Pins Procurement Notes

Verify that the specific suffix matches the required contact length and plating thickness for your application. Confirm RoHS compliance status and moisture sensitivity level requirements against your manufacturing process specifications. Ensure the reel quantity aligns with your production line capacity.

Headers, Male Pins Selection Notes

Select this component when a low-profile surface mount header is required for rigid board connections. Consider the TSM series flexibility if variable stack heights are needed. Evaluate the thermal operating range to ensure compatibility with soldering profiles and environmental conditions.

Headers, Male Pins Part Context

This part belongs to the TSM flexible stacking solutions family, designed for high-reliability interconnects. The TSM series allows for custom lengths and heights within standard pitch constraints. It serves as a robust alternative to traditional through-hole headers in space-constrained designs.

Headers, Male Pins Replacement Considerations

Direct substitutes include other Samtec TSM series headers with identical pitch and row count. Verify mechanical dimensions and contact material compatibility before cross-referencing with generic SMT headers.
