TSM-108-04-L-SH-A-TR

Headers, Male Pins Overview

The TSM-108-04-L-SH-A-TR is a surface mount terminal strip header manufactured by Samtec. It features an unshrouded design with a .100 inch (2.54 mm) pitch and four positions in a single row. The connector utilizes male square pins designed for right-angle board mounting. The component is constructed with black liquid crystal polymer insulation and phosphor bronze contacts. It is classified as an Extended Life Product, indicating enhanced durability and reliability for demanding applications.

Headers, Male Pins Feature Summary

• Unshrouded surface mount terminal strip header with right-angle orientation
• Compatible with .025 inch square post mating systems for high cycle life
• Designed for automated pick-and-place assembly processes
• Constructed with black liquid crystal polymer insulator material

Headers, Male Pins Applications

• High-density board-to-board interconnections
• Automotive electronics requiring extended life reliability
• Industrial control systems with high mating cycle demands
• Data communication equipment utilizing square post mating interfaces

Headers, Male Pins Procurement Notes

Verify the specific suffix codes against official Samtec documentation to confirm pin configuration, plating options, and reel packaging details. Ensure the selected variant matches the required right-angle orientation and surface mount termination style for your PCB layout. Cross-reference the part number with the manufacturer's current datasheet to validate compliance with RoHS standards and environmental testing requirements before finalizing procurement.

Headers, Male Pins Selection Notes

Select this component when a low-profile, single-row surface mount header is required for right-angle connections. The unshrouded design allows for flexible mating options with various socket types. Consider the mechanical stability provided by the square post interface if high durability is needed. Evaluate the thermal performance of the liquid crystal polymer insulator against your operating temperature range to ensure long-term reliability under stress.

Headers, Male Pins Part Context

This part belongs to the TSM series of surface mount terminal strips from Samtec. The series offers various row counts and pin configurations to suit different density requirements. These headers are engineered for robust performance in environments where standard connectors might fail due to vibration or frequent connection cycles. The specific model denotes a four-position variant within this extensive family of interconnect solutions.

Headers, Male Pins Replacement Considerations

Direct substitutes include other Samtec TSM series variants with matching pitch and position counts, such as TSM-108-04-L-SH-TR. Verify that any replacement maintains the same right-angle orientation and surface mount termination style. Ensure the mating partner uses compatible .025 inch square posts to preserve the intended mechanical and electrical performance characteristics.
