TSM-110-01-L-SH-LC-TR

Headers, Male Pins Overview

The TSM-110-01-L-SH-LC-TR is a surface mount header manufactured by Samtec Inc. It features a 2.54 mm (0.100 inch) pitch with two rows and ten positions per row, totaling twenty contacts. The connector utilizes phosphor bronze contacts with gold plating for reliable signal transmission. Designed for right-angle surface mount installation, it employs liquid crystal polymer insulation rated UL94 V-0. The component supports operating temperatures ranging from -55°C to +125°C and is supplied in tape-and-reel packaging for automated assembly processes.

Headers, Male Pins Feature Summary

• Designed specifically for surface mount applications with mixed technology pin options
• Features standard post heights compatible with various Samtec socket solutions
• Constructed with high-performance materials including LCP insulation and gold-plated phosphor bronze contacts

Headers, Male Pins Applications

• High-density board-to-board interconnections
• Automotive electronics assemblies requiring robust surface mounting
• Industrial control systems utilizing mixed termination technologies

Headers, Male Pins Procurement Notes

Verify the specific suffix codes against official Samtec documentation to confirm exact contact configuration and plating thickness. Ensure that the reel quantity matches production requirements. Confirm RoHS compliance status and moisture sensitivity level prior to inventory acceptance. Cross-reference the part number with current datasheets to validate any recent design changes or obsolescence notices.

Headers, Male Pins Selection Notes

Select this component when right-angle surface mount headers are required for 2.54 mm pitch applications. Consider the mechanical stability of the right-angle orientation for PCB layout constraints. Evaluate the thermal performance of the LCP material against the operational environment. Ensure mating connectors align with the specified contact height and post dimensions for proper engagement.

Headers, Male Pins Part Context

This part belongs to the TSM series of .100" Surface Mount Terminal Strips. The series offers single, double, and triple row configurations with vertical, horizontal, or mixed technology pins. These components are classified as Extended Life Products, undergoing rigorous testing for corrosion resistance and mating cycles. The series provides flexible solutions for modern electronic manufacturing needs.

Headers, Male Pins Replacement Considerations

Consult official Samtec substitution guides for verified alternatives. Generic equivalents may not match the precise contact geometry or material specifications required for reliable performance.
