TSM-110-02-TM-SH-A-P-TR

Headers, Male Pins Overview

The TSM-110-02-TM-SH-A-P-TR is a surface-mount header manufactured by Samtec Inc., featuring 10 positions arranged in a single row. It utilizes a 0.100 inch (2.54 mm) pitch with male square pin contacts. The connector is designed for right-angle installation and includes an integrated shroud. Contact materials consist of phosphor bronze with tin plating, while the insulation is constructed from polyphenylene sulfide. It supports a temperature range of -55°C to 125°C and meets UL94 V-0 flammability standards.

Headers, Male Pins Feature Summary

• Right-angle surface mount design for compact board integration
• Integrated shroud provides alignment and protection
• Tin-plated phosphor bronze contacts ensure reliable conductivity

Headers, Male Pins Applications

• Board-to-board interconnections
• Compact electronic assemblies requiring right-angle routing
• Industrial control modules

Headers, Male Pins Procurement Notes

Verify the specific suffix 'P-TR' confirms the tape-and-reel packaging format required for automated pick-and-place assembly processes. Ensure compatibility with standard SMD reflow soldering profiles. Confirm that the right-angle orientation matches the PCB layout requirements before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this component when a low-profile, right-angle connection is necessary within constrained vertical spaces. The single-row configuration suits applications requiring fewer signal lines. Verify that the 2.54 mm pitch aligns with existing mating connectors or cable harnesses to ensure mechanical fit and electrical continuity.

Headers, Male Pins Part Context

This part belongs to the TSM series of surface-mount headers from Samtec. These connectors are characterized by their robust construction and suitability for high-density applications. The series offers various configurations, including shrouded and unshrouded options, catering to diverse board-to-board connectivity needs in modern electronics manufacturing.

Headers, Male Pins Replacement Considerations

Direct substitutes include other 10-position, 2.54mm pitch right-angle SMD headers with shrouds. Verify identical mechanical dimensions and contact plating specifications when evaluating alternative manufacturers to maintain performance consistency.
