TSM-110-03-L-DH-A-K-TR

Headers, Male Pins Overview

The TSM-110-03-L-DH-A-K-TR is a board connector featuring 30 contacts arranged in three rows. It utilizes a .100 inch (2.54 mm) pitch and employs .025 inch square post terminals for mating. The component is designed for surface mount termination with straight orientation. It includes pick-and-place pads to facilitate automated assembly processes. The housing is constructed from black insulating material, and the contacts are configured as male pins.

Headers, Male Pins Feature Summary

• Features .025 inch square post terminal system for high durability
• Designed specifically for surface mount applications
• Includes pick-and-place pads for automated processing
• Qualified under Severe Environment Testing (SET) standards

Headers, Male Pins Applications

• Automotive electronics systems
• High-speed data transmission interfaces
• Industrial control boards
• Communication equipment modules

Headers, Male Pins Procurement Notes

Verify that the specific suffixes match the required configuration, particularly regarding the tape and reel packaging indicated by -TR and the pick-and-place pad option denoted by -P or similar designators in the full part number structure. Confirm the contact plating specifications align with environmental requirements. Ensure the manufacturer source is authorized to guarantee authenticity and traceability of the SET qualified components.

Headers, Male Pins Selection Notes

Select this component when surface mount technology is required for robust interconnections. The three-row configuration supports higher density connections compared to single-row options. Consider the .100 inch pitch compatibility with existing socket designs. Evaluate the need for mixed-flowing gas corrosion resistance provided by the Extended Life Product designation for long-term reliability in harsh environments.

Headers, Male Pins Part Context

This part belongs to the TSM series of .100 inch surface mount terminal strips manufactured by Samtec. The series offers various row counts and termination styles to accommodate different board layout constraints. It is categorized as an Extended Life Product, indicating enhanced performance characteristics beyond standard industrial connectors.

Headers, Male Pins Replacement Considerations

Direct substitutes within the same series include variations in row count or termination style such as TSM-110-03-F-DH-A-K-TR or TSM-110-03-S-DH-A-K-TR. Cross-series replacements require verification of pitch, contact count, and mounting orientation to ensure mechanical and electrical compatibility.
