TSM-110-04-L-DV-A

$2.53

Description：CONN HEADER SMD 20POS 2.54MM
Series：TSM
Mfr：Samtec Inc.
Package：Bulk,Tube

SKU:2b67a990ec73 Category: Headers, Male Pins Brand: Samtec Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

TSM-110-04-L-DV-A is listed in the Headers, Male Pins range at ChipApex. The manufacturer field lists Samtec Inc.. Its product description is CONN HEADER SMD 20POS 2.54MM. Review the specifications below when checking this part for your BOM.

Headers, Male Pins specifications for TSM-110-04-L-DV-A

Description：CONN HEADER SMD 20POS 2.54MM
Series：TSM
Mfr：Samtec Inc.
Package：Bulk,Tube
Connector Type：Header, Cuttable
Contact Type：Male Pin
Pitch - Mating：0.100" (2.54mm)
Number of Positions：20
Number of Rows：2
Row Spacing - Mating：0.100" (2.54mm)
Number of Positions Loaded：All
Style：Board to Board or Cable
Shrouding：Unshrouded
Mounting Type：Surface Mount
Termination：Solder
Fastening Type：Push-Pull
Contact Length - Mating：0.120" (3.05mm)
Contact Length - Post：-
Overall Contact Length：-
Insulation Height：0.100" (2.54mm)
Contact Shape：Square
Contact Finish - Mating：Gold
Contact Finish Thickness - Mating：10.0µin (0.25µm)
Contact Finish - Post：Tin
Contact Material：Phosphor Bronze
Insulation Material：Liquid Crystal Polymer (LCP)
Features：Board Guide
Operating Temperature：-55°C ~ 125°C
Ingress Protection：-
Material Flammability Rating：UL94 V-0
Insulation Color：Black
Current Rating (Amps)：-
Voltage Rating：-

Headers, Male Pins datasheet and documents for TSM-110-04-L-DV-A

TSM-110-04-L-DV-A

Headers, Male Pins Overview

Samtec TSM-110-04-L-DV-A is a .100" (2.54mm) pitch surface mount terminal strip featuring two rows and twenty positions. The connector utilizes phosphor bronze contacts with gold plating for reliable signal transmission. Designed for vertical installation, it supports solder pin termination suitable for SMD/SMT processes. The housing is constructed from black liquid crystal polymer (LCP), offering UL 94 V-0 flammability ratings. It operates within a temperature range of -55°C to +125°C and provides a voltage rating of 495 VAC.

Headers, Male Pins Feature Summary

Surface mount design optimized for automated pick-and-place assembly
Flexible stacking capability allows for various board-to-board configurations
Gold-plated square contact system ensures durable mating cycles

Headers, Male Pins Applications

High-density board-to-board interconnects
Automotive electronics assemblies
Industrial control systems requiring robust surface mounting

Headers, Male Pins Procurement Notes

Verify the specific suffix codes against official Samtec documentation to confirm exact physical dimensions and termination styles. Ensure compatibility with standard reflow profiles for LCP materials. Cross-reference the manufacturer part number with authorized distributor catalogs to validate current availability status and lead times before finalizing procurement plans.

Headers, Male Pins Selection Notes

Select this component when a rigid .100" pitch header is required for surface mounting applications. Consider the straight pin configuration for standard vertical connections. Evaluate the thermal performance limits relative to the operating environment. Confirm that the contact length matches the mating socket requirements for proper engagement depth.

Headers, Male Pins Part Context

The TSM series represents Samtec's line of flexible stacking solutions designed for high-reliability interconnects. This specific model belongs to the standard terminal strip family, providing a cost-effective alternative to more complex flexible cable assemblies while maintaining high performance standards in demanding electronic environments.
