TSM-110-04-S-DV-P-TR

Headers, Male Pins Overview

The TSM-110-04-S-DV-P-TR is a surface mount header from the Samtec TSM series, featuring a 2.54 mm (0.100 inch) pitch and double-row configuration with 20 positions. It utilizes phosphor bronze contacts with gold plating and liquid crystal polymer insulation rated UL94 V-0. Designed for board-to-board or cable applications, it supports pick-and-place assembly and operates within a temperature range of -55°C to +125°C.

Headers, Male Pins Feature Summary

• Double vertical surface mount design facilitates automated pick-and-place processing.
• Flexible stacking solutions allow mating with various socket heights.
• Gold-plated phosphor bronze contacts ensure reliable electrical performance.

Headers, Male Pins Applications

• Board-to-board interconnections
• Cable connections
• High-density electronic assemblies

Headers, Male Pins Procurement Notes

Verify the specific suffix codes against official datasheets to confirm contact length and termination style. Ensure compatibility with surface mount reflow profiles. Confirm RoHS compliance status through manufacturer documentation prior to integration into production workflows.

Headers, Male Pins Selection Notes

Select this component for high-density surface mount applications requiring flexible stacking heights. The double-row vertical format optimizes PCB space while maintaining signal integrity. Consider mating connector post lengths to ensure proper engagement depth.

Headers, Male Pins Part Context

This part belongs to the TSM .100" Surface Mount Terminal Strip family. It offers versatile mounting options including horizontal and vertical configurations. The series is engineered for severe environment testing and meets MIL-DTL-55302 standards for reliability in demanding conditions.

Headers, Male Pins Replacement Considerations

Cross-reference with other TSM series variants for different row counts or contact materials. Verify identical pitch and mechanical dimensions when substituting. Consult official cross-reference lists for confirmed equivalent part numbers.
