TSM-111-03-S-DV

Headers, Male Pins Overview

The TSM-111-03-S-DV is a dual-row male pin header from the Samtec Tiger Claw series, designed for surface mount applications. It features 22 positions with a 2.54 mm (0.100 inch) pitch and straight orientation. The connector utilizes .025 inch square posts for contact termination and gold plating over nickel. It is intended for board-to-board connections in high-density electronic assemblies.

Headers, Male Pins Feature Summary

• Tiger Claw contact system provides secure mating with socket counterparts
• Surface mount design facilitates automated PCB assembly processes
• Dual-row configuration supports high I/O density in compact footprints

Headers, Male Pins Applications

• Board-to-board interconnections
• High-density electronic assemblies
• Automotive electronics modules

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix to confirm contact plating and termination style. Ensure the selected variant matches the required post height for mating compatibility. Confirm RoHS compliance status through official documentation before procurement.

Headers, Male Pins Selection Notes

Select this component when surface mount termination is required for dual-row headers. Consider the 2.54 mm pitch for standard spacing needs. Evaluate the mechanical profile against available vertical clearance on the target PCB layout.

Headers, Male Pins Part Context

This part belongs to the TSM series of surface mount terminal strips. It complements other Samtec connectors by offering a reliable male interface for socket-based systems. The series supports various post heights and termination options for diverse mounting requirements.

Headers, Male Pins Replacement Considerations

No public confirmed substitute part numbers are identified in the provided documentation. Verify mechanical dimensions and electrical ratings before considering alternative components.
