TSM-113-04-G-SV-LC-007-P-TR

Headers, Male Pins Overview

The TSM-113-04-G-SV-LC-007-P-TR is a board connector manufactured by Samtec Inc. It features 13 contacts arranged in a single row with male pin terminals. The component utilizes surface mount termination and is designed for straight installation. The contact pitch is 0.1 inch (2.54 mm). The connector body measures 1.3 inches in length, 0.15 inches in depth, and 0.1 inch in width. Contact finishes include gold over nickel. The housing is black and the unit is RoHS compliant.

Headers, Male Pins Feature Summary

• Surface mount terminal configuration for direct PCB attachment
• Male pin contact style with rectangular arrangement
• Gold plating over nickel barrier on contact surfaces

Headers, Male Pins Applications

• Board-to-board interconnection systems
• High-density electronic assembly integration
• Surface mount circuit board connections

Headers, Male Pins Procurement Notes

Verify that the specific suffix LC-007-P corresponds to the required lead time or custom specification rather than standard stock availability. Confirm the tape and reel packaging format matches the automated assembly requirements. Ensure the RoHS compliance status aligns with current regulatory standards for the target market. Cross-reference the exact part number to distinguish between standard header variants and those with specific tail lengths or shrouding options.

Headers, Male Pins Selection Notes

Select this component when a single-row male header with surface mount capability is required. The 0.1 inch pitch suits general-purpose digital and analog signal routing. Consider the unshrouded design for applications where mating guide rails are present. Evaluate the mechanical stability provided by the PEG option if additional retention during soldering is needed. Ensure the board space accommodates the 1.3-inch length constraint.

Headers, Male Pins Part Context

This part belongs to the TSM series of .025 square terminal strips produced by Samtec. The series offers various configurations for board-to-board connectivity. The TSM-113-04-G-SV-LC-007-P-TR variant specifically denotes a 13-position header with surface mount terminals and a particular tail length or packaging specification indicated by the suffixes. It represents a standard solution for high-reliability interconnect needs.

Headers, Male Pins Replacement Considerations

Compatible substitutes include TSM-113-04-G-SV-LC and TSM-113-04-G-SV-P-TR from Samtec. Verify that alternative parts maintain the same 13-position count and 0.1 inch pitch. Ensure the replacement also supports surface mount termination and male pin configuration. Check if the specific LC-007-P tail length requirement can be met by the generic SV variant.
