TSM-115-01-SM-SH

Headers, Male Pins Overview

The TSM-115-01-SM-SH is a surface mount terminal strip manufactured by Samtec Inc. It features a single row of 15 male pins with a 0.100 inch (2.54 mm) pitch. The connector utilizes .025 inch square posts and is designed for right-angle surface mount termination. The contacts are constructed from phosphor bronze with gold plating over nickel, ensuring reliable electrical performance in board-to-board applications.

Headers, Male Pins Feature Summary

• Designed specifically for surface mount applications with mixed technology pin options
• Features .025 inch square post terminals for robust mechanical connection
• Available as an Extended Life Product™ meeting rigorous environmental standards

Headers, Male Pins Applications

• Board-to-board interconnections requiring high reliability
• High-speed data transmission systems up to 8 Gbps
• Automotive A-Series product implementations

Headers, Male Pins Procurement Notes

Verify the specific suffix configuration against official Samtec documentation to ensure correct pin orientation and termination style. Confirm RoHS compliance status and mating partner compatibility before integration. Cross-reference the exact part number with manufacturer datasheets to validate current production status and lead times.

Headers, Male Pins Selection Notes

Select this component when right-angle surface mount connectivity is required for dense PCB layouts. Consider the 0.100 inch pitch and single-row configuration for space-constrained designs. Evaluate the extended life product specifications if the application demands high mating cycles or exposure to harsh environments.

Headers, Male Pins Part Context

This part belongs to the TSM series of flexible stacking solutions from Samtec. The series offers various row counts and termination styles to accommodate diverse assembly needs. The TSM-115 variant specifically denotes a 15-position configuration within this standardized lineup of high-performance interconnects.

Headers, Male Pins Replacement Considerations

Consult official Samtec substitution guides for verified equivalents. Generic connectors may not match the .025 inch square post geometry or surface mount footprint requirements.
