TSM-116-02-F-DH

Headers, Male Pins Overview

The TSM-116-02-F-DH is a surface mount board connector from the Samtec TSM series, featuring a .100 inch (2.54 mm) pitch and 16 contacts in a single row. It utilizes male square pin sockets with phosphor bronze material and matte tin over nickel plating. The component measures 1.6 inches in length, 0.24 inches in width, and 0.41 inches in depth. Designed for high reliability, it qualifies as an Extended Life Product™, passing 10-year Mixed Flowing Gas corrosion testing and supporting up to 2,500 mating cycles.

Headers, Male Pins Feature Summary

• Extended Life Product™ qualification ensuring resistance to harsh environmental conditions
• High durability with support for up to 2,500 mating cycles
• Surface mount termination technology optimized for automated processing
• Compatible with standard socket solutions through selectable post heights

Headers, Male Pins Applications

• Automotive electronics systems requiring high cycle life
• Industrial control boards needing reliable surface mount connections
• Communication equipment utilizing high-speed signal transmission
• Consumer electronics demanding compact board-to-board interconnects

Headers, Male Pins Procurement Notes

Verify that the specific ordering suffix matches the required contact plating and termination style. Confirm the package type aligns with your assembly process requirements. Ensure compatibility with the mating connector's pin configuration. Check for any specific RoHS compliance documentation if required by your supply chain standards. Validate the lead time against production schedules before finalizing orders.

Headers, Male Pins Selection Notes

Choose this component when surface mount technology is preferred over through-hole for space constraints. Select this model for applications requiring high insertion-extraction durability. Consider this part for designs needing standardized .100 inch spacing. Evaluate the extended life features for long-term operational reliability needs. Ensure the single-row configuration fits the available PCB footprint area.

Headers, Male Pins Part Context

This connector belongs to the TSM series of flexible stacking solutions. It complements other surface mount terminal strips offering various row configurations. The series supports both vertical and horizontal orientations. It integrates with Samtec's broader ecosystem of high-reliability interconnect products. The design facilitates efficient manufacturing processes through pick-and-place compatibility.

Headers, Male Pins Replacement Considerations

Direct substitutes within the same series include variants with different plating options or row counts. Cross-reference part numbers sharing the TSM-116 base identifier. Verify mechanical dimensions match existing PCB layouts before substitution. Ensure electrical characteristics remain compatible with the original design specifications.
