TSM-119-02-L-SH-A-P

Headers, Male Pins Overview

The TSM-119-02-L-SH-A-P is a board-to-board connector from the Samtec Tiger Eye series, designed for surface mount applications. It features a .100 inch (2.54 mm) pitch with 19 contacts arranged in a single row. The male header utilizes .025 inch square post terminals made of phosphor bronze with gold plating over nickel. The insulator is constructed from black liquid crystal polymer (LCP), rated UL 94 V-0. It supports data rates up to 8 Gbps NRZ and operates within a temperature range of -55°C to +125°C.

Headers, Male Pins Feature Summary

• Surface mount terminal strip design with straight orientation
• Gold-plated .025 inch square post contacts for reliable connection
• High-speed signal integrity supporting up to 8 Gbps performance

Headers, Male Pins Applications

• High-density board-to-board interconnects
• Mezzanine connections in compact electronic modules
• Signal transmission in high-speed digital systems

Headers, Male Pins Procurement Notes

Verify the specific ordering suffixes to ensure correct termination style and contact configuration. Confirm that the selected variant matches the required pitch and contact count for the target PCB layout. Check RoHS compliance status against current regulatory requirements before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this component when a low-profile, surface-mount male header is required for rigid board stacking. Ensure the mating socket provides compatible .025 inch square post receptacles. Consider thermal management capabilities given the LCP insulator material and operating temperature limits during system integration.

Headers, Male Pins Part Context

This part belongs to the Tiger Eye SMT Terminal Strip family, known for its robust mechanical stability and high cycle life. The series offers various row configurations and termination options to accommodate diverse assembly needs while maintaining consistent electrical performance across different industrial environments.

Headers, Male Pins Replacement Considerations

Direct substitutes include other Samtec Tiger Eye headers with identical pitch and contact counts, such as TSM-119-02-L-SH-K-TR. Verify pinout compatibility and mechanical footprint dimensions before swapping components in existing designs.
