TSM-120-01-T-DH-LC

Headers, Male Pins Overview

The TSM-120-01-T-DH-LC is a surface mount terminal strip header manufactured by Samtec Inc. It features 20 positions with a single row configuration and a 0.100-inch (2.54mm) pitch. The connector utilizes .025 inch square posts for mating compatibility. It employs tin-plated phosphor bronze contacts housed in black liquid crystal polymer insulation. Designed for right-angle surface mount termination, it supports board-to-board or cable applications within an operating temperature range of -55°C to 105°C.

Headers, Male Pins Feature Summary

• Features .025 inch square post terminals designed for high-density arrays and flexible stacking solutions.
• Constructed as an Extended Life Product™ capable of passing 10-year Mixed Flowing Gas testing.
• Supports mixed technology pin options including straight, right-angle, and vertical orientations.

Headers, Male Pins Applications

• High-speed board-to-board interconnections requiring up to 8 Gbps performance.
• Automotive A-Series product integration and severe environment testing applications.
• General electronic assemblies utilizing standard socket mating solutions.

Headers, Male Pins Procurement Notes

Verify the specific suffix codes against official Samtec documentation to confirm exact pin style and packaging variations. Ensure the selected variant matches the required PCB footprint and mounting orientation. Confirm RoHS3 compliance status directly from the manufacturer datasheet prior to final design approval.

Headers, Male Pins Selection Notes

Select this component when a right-angle surface mount header with .025 inch square posts is required. Consider the Extended Life Product rating for environments demanding high mating cycles and corrosion resistance. Evaluate thermal requirements against the specified -55°C to 105°C operating range.

Headers, Male Pins Part Context

This part belongs to the TSM series of .100 inch surface mount terminal strips. The series offers single, double, and triple row options with various termination technologies. It is engineered for high-density arrays and provides robust mechanical stability for critical interconnect applications.

Headers, Male Pins Replacement Considerations

Public confirmed substitute part numbers are not available in the provided source material. Consult Samtec engineering for potential cross-references based on specific electrical and mechanical constraints.
