TSM-144-01-T-DV

Headers, Male Pins Overview

The Samtec TSM-144-01-T-DV is a surface mount pin header strip featuring a 2.54 mm (0.100 in) pitch and two rows of contacts. It provides 144 positions with tin-plated phosphor bronze terminals housed in black liquid crystal polymer (LCP). The component supports a current rating of 4.1 A to 5.4 A and a voltage rating of 495 VAC, operating within a temperature range of -55°C to +105°C. It utilizes a push-pull fastening mechanism and meets UL 94 V-0 flammability standards.

Headers, Male Pins Feature Summary

• Low profile surface mount design for space-constrained applications
• Push-pull fastening system ensures secure board retention
• High insulation material compatibility with lead-free soldering processes

Headers, Male Pins Applications

• Board-to-board interconnections in compact electronic assemblies
• Surface mount integration for high-density signal routing
• Industrial control modules requiring robust thermal stability

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix against the official Samtec datasheet to confirm exact contact length, insulation height, and termination style. Ensure the selected variant matches the required PCB footprint and mating connector specifications before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this component when a standard 0.100-inch pitch surface mount header is required. Confirm that the 144-position count aligns with circuit density needs. Validate that the 2.54 mm insulation height fits within the mechanical clearance constraints of the target enclosure or adjacent components.

Headers, Male Pins Part Context

This part belongs to the TSM series of flexible stacking solutions from Samtec. These headers are designed for high-reliability interconnects in demanding environments. The TSM series offers various configurations to accommodate different board thicknesses and mating requirements while maintaining consistent electrical performance.

Headers, Male Pins Replacement Considerations

Consult the official Samtec cross-reference guide for verified substitutes. Generic equivalents may not match the precise push-pull mechanism or LCP material properties required for reliable operation.
