TSP-H00HM50RT-8.000M

Oscillators Overview

The TSP-H00HM50RT-8.000M is a standard crystal oscillator manufactured by Transko Electronics, Inc., designed for surface-mount applications. It operates at a fixed frequency of 8 MHz with an HCMOS output logic level. The device features a 5V supply voltage and includes an enable/disable control function for power management. It is housed in a 4-SOJ package with a 5.08mm pitch, measuring 14.0 x 9.8 x 4.7mm. The unit supports an operating temperature range of 0°C to 70°C and has a maximum supply current of 45mA.

Oscillators Feature Summary

• Integrated enable and disable functionality for controlled power consumption
• HCMOS output interface compatible with standard digital logic circuits
• Surface-mount construction in a compact 4-SOJ package

Oscillators Applications

• General-purpose clock signal generation in electronic systems
• Timing reference for microcontroller-based embedded designs
• Synchronization sources for digital communication interfaces

Oscillators Procurement Notes

Verify the specific ordering suffix against official manufacturer documentation to confirm pinout compatibility and electrical specifications. Ensure that the selected variant matches the required frequency tolerance and load capacitance for the target circuit design. Cross-reference the package dimensions with PCB footprint libraries to guarantee accurate mechanical fit during assembly.

Oscillators Selection Notes

Select this component when a stable 8 MHz timing source is required for HCMOS-compatible logic families. Consider the 0°C to 70°C operating range for commercial-grade environments. Evaluate the 45mA maximum current draw against system power budgets. Confirm that the 4-SOJ package orientation aligns with available board space and manufacturing capabilities.

Oscillators Part Context

This oscillator belongs to the TSP series of plastic molded standard SMD oscillators from Transko Electronics. The series typically offers various frequencies and output types within similar form factors. This specific model represents a standard configuration optimized for general industrial and commercial applications requiring reliable clock signals.

Oscillators Replacement Considerations

Direct substitutes include other 8 MHz HCMOS oscillators in 4-SOJ packages from compatible manufacturers. Verify equivalent supply voltage, current consumption, and frequency stability before substitution. Ensure thermal characteristics match the original design requirements.
