TSP-H50CQ33RT-40.000M

Oscillators Overview

The TSP-H50CQ33RT-40.000M is a standard crystal oscillator (XO) manufactured by Transko Electronics, Inc., operating at a nominal frequency of 40 MHz. It utilizes HCMOS output logic and functions with a 3.3V supply voltage. The device features an enable/disable control function for power management. It is housed in a 4-SOJ package with a 5.08mm pitch. Key electrical specifications include a frequency stability of ±50ppm and an operating temperature range of -40°C to +85°C.

Oscillators Feature Summary

• HCMOS output signal generation
• Enable/Disable control functionality
• SOJ surface-mount packaging

Oscillators Applications

• General-purpose clock signal distribution
• Embedded system timing references
• Industrial control equipment

Oscillators Procurement Notes

Verify the specific suffix codes against official Transko documentation to confirm exact pinout configuration and tolerance levels. Ensure that the SOJ package dimensions align with the target PCB footprint requirements. Confirm that the 3.3V supply voltage matches the system design constraints before finalizing procurement orders.

Oscillators Selection Notes

Select this component when a robust SOJ package is required over smaller SMD alternatives for improved mechanical shock resistance. Consider the ±50ppm stability specification relative to system timing requirements. Evaluate the enable/disable feature necessity for power-sensitive applications within the specified industrial temperature range.

Oscillators Part Context

This part belongs to the Transko standard XO series, designed for reliable clock generation in electronic circuits. The TSP series typically offers various output types and frequencies. This specific model provides a balance of performance and mechanical durability through its plastic molded construction and standardized lead spacing.

Oscillators Replacement Considerations

Direct substitutes may include other 40MHz HCMOS oscillators in SOJ-4 packages from Transko or competitors, provided they match the 3.3V supply, ±50ppm stability, and enable/disable functionality. Verify pin compatibility and thermal characteristics before substitution.
