TSR 0.5-2465SM

TSR 0.5-2465SM is listed in the DC DC Converters range at ChipApex. The manufacturer field lists Traco Power. Its product description is DC DC CONVERTER 6.5V 3.3W. Review the specifications below when checking this part for your BOM.

DC DC Converters specifications for TSR 0.5-2465SM

• Description：DC DC CONVERTER 6.5V 3.3W
• Series：TSR 0.5SM
• Mfr：Traco Power
• Package：Tube
• Type：Linear Regulator Replacement
• Number of Outputs：1
• Voltage - Input (Min)：8V
• Voltage - Input (Max)：32V
• Voltage - Output 1：6.5V
• Voltage - Output 2：-
• Voltage - Output 3：-
• Voltage - Output 4：-
• Current - Output (Max)：500mA
• Power (Watts)：3.3 W
• Voltage - Isolation：-
• Applications：ITE (Commercial)
• Features：Remote On/Off, OTP, SCP
• Operating Temperature：-40°C ~ 90°C (With Derating)
• Efficiency：95%
• Mounting Type：Surface Mount
• Package / Case：10-SMD Module
• Size / Dimension：0.60" L x 0.38" W x 0.36" H (15.3mm x 9.6mm x 9.2mm)
• Supplier Device Package：-
• Control Features：-
• Approval Agency：-
• Standard Number：-
• Grade：-
• Qualification：-
