TSR 0.6-48120WI

TSR 0.6-48120WI is listed in the DC DC Converters range at ChipApex. The manufacturer field lists Traco Power. Its product description is DC DC CONVERTER 12V 3SIP. Review the specifications below when checking this part for your BOM.

DC DC Converters specifications for TSR 0.6-48120WI

• Description：DC DC CONVERTER 12V 3SIP
• Series：TSR 0.6WI
• Mfr：Traco Power
• Package：Tube
• Type：Non-Isolated PoL Module
• Number of Outputs：1
• Voltage - Input (Min)：17V
• Voltage - Input (Max)：72V
• Voltage - Output 1：12V
• Voltage - Output 2：-
• Voltage - Output 3：-
• Voltage - Output 4：-
• Current - Output (Max)：600mA
• Power (Watts)：-
• Voltage - Isolation：-
• Applications：ITE (Commercial)
• Features：-
• Operating Temperature：-40°C ~ 85°C (With Derating)
• Efficiency：93%
• Mounting Type：Through Hole
• Package / Case：3-SIP Module
• Size / Dimension：0.47" L x 0.34" W x 0.53" H (12.0mm x 8.6mm x 13.4mm)
• Supplier Device Package：-
• Control Features：-
• Approval Agency：-
• Standard Number：-
• Grade：-
• Qualification：-
